20KG Servo Motors, Metal Gear Steering Servo for RC Car Robot DIY, Control Angle 180, with High Rotation

Description

• High Rotation: With a 180 degree rotation range and excellent linearity, this servo enables control andmovement. It can rotate 360 degrees even when power is off, making it ideal for robot joint activities.
• Design: This robot digital servo features a design with a coreless metal gear system. It provides a highof performance and durability.
• Strong Performance: The servo also features a hard anodized aluminum casing for improved strength and heat dissipation, along with dual ball bearings for enhanced longevity.
• Gear Construction: Built with high performance digital standard servo technology, this servo utilizes highmetal gears and stainless steel gears, with a highof reliability and stability.
• Wide Applications: Digital servo is widely used in various applications such as robots, robotic arms, crawlers, remote controlled boats, and remote controlled aircraft, making it suitable for a wide range of projects.

1. High Rotation: With a 180 degree rotation range and excellent linearity, this servo enables control andmovement. It can rotate 360 degrees even when power is off, making it ideal for robot joint activities.
2. Design: This robot digital servo features a design with a coreless metal gear system. It provides a highof performance and durability.
3. Strong Performance: The servo also features a hard anodized aluminum casing for improved strength and heat dissipation, along with dual ball bearings for enhanced longevity.
4. Gear Construction: Built with high performance digital standard servo technology, this servo utilizes highmetal gears and stainless steel gears, with a highof reliability and stability.
5. Wide Applications: Digital servo is widely used in various applications such as robots, robotic arms, crawlers, remote controlled boats, and remote controlled aircraft, making it suitable for a wide range of projects.

Spec:
Item Type: Robot Digital Servo
Material: Metal
Mechanical Parameter:
Mechanism Limit Angle: unlimited
Output Shaft: 25T 5.9mm
Bearing Type: Ball bearings
Motor Type: Core Motor
Electrical Parameter
Operating Voltage: 6V/7.4V
No Load Speed: 0.185sec/ 60/0.151sec/60
No Load Current: 100mA/120mA
Lock Torsion: 20.5Kg.cm/ 25 kg.cm
Locked Rotor Current: 3.0A/3.5A
Rated Load: 7Kg.cm/8Kg.cm
Rated Current: 1000mA/1200mA
Voltage Range: 4V-8.4V
Kt Constant: 7Kg.cm/A

How to Use:
install and use

Package List:
1 x Digital Servo
1 x 25T Servo Arm
5 x Accessories
4 x Rubber Sleeve
10 x Screw
